This Tweezers The LCN-PINZ is a special tweezers designed for unlocking the LCN glass surface buttons. These buttons are equipped with a lateral locking pin that can be easily removed with the tweezers without causing damage. This greatly facilitates the installation and maintenance of the buttons. Application Examples Installation of LCN glass surface buttons Maintenance and replacement of buttons without damage Technical Data Ergonomic design for easy handling Material: High-quality plastic

Sensor/Actuator module for flush-mounted installation Combined sensor/actuator module with two electronic switching outputs 230V, 300VA. Dimmable in phase-cut or as a switch (switches at zero crossing). The 8 button inputs can individually control 64 target addresses with 192 functions. Integrated pulse measurement input for remote control receivers. The built-in operating program includes the following functions: switching and dimming of the outputs, brightness and change speed can be set separately. Includes programs for incandescent lamp dimming, roller shutters, gates, etc. Evaluation via 5 thresholds (=10 commands) with hysteresis. Includes 2 continuous controllers that can be used independently and in addition to threshold processing. Two measured values can be captured and controlled independently of each other. Decoding of telegrams from the IR remote control receiver or transponder. Evaluation directly or via central computer. Functions for button levels, coded transmission, sender differentiation. Additional functions: control with dependencies, formation of links, counting, calculating, fixed and dynamic group formation, generation of automatic status messages (real feedback) for visualization. LCN System Bus Functions Communication with up to 30000 modules, max. 250 modules per bus level. Protocol with collision avoidance Documentation and parameterization retrievable in the module memory 100 light scene memories available per output Connection options for EIB/KNX touch sensors (standard), DSI-Dali interface, relays Overload protection, the outputs switch off consumers at excessive loads Note: UPP modules must not be connected directly to roller shutter or blind motors! The limit switches or the triacs in the module may be damaged. The use of the relay LCN-R2U is recommended. A filter (LCN-FI1) is mandatory as soon as the electronic outputs of the LCN-UPP are used as dimmers. The interference filter is connected between the module and the consumer, dampening the disturbances that occur during dimming, thus ensuring compliance with CE standards. Technical Data Integrated power supply 230V ±15%, 0.4W, pulse-resistant up to 4kV. Flush-mounted housing connection via approx. 20cm long single wires 0.75mm². Dimensions: 50mm Ø x 20mm. Protection class IP20

Universal Roller Shutter/Jalousie Module for Flush-Mounting Box The LCN-UMR24 is an advanced sensor-actuator module designed for controlling roller shutter and jalousie motors with a supply voltage of 24V.

Sensor/Actuator module for flush-mounted boxes with phase-cut and phase-angle dimming The LCN-UPU module is an innovative sensor/actuator module designed for use in flush-mounted boxes. It allows for the control of two electronic outputs with 230V, either switching or dimming. The module is ideal for controlling lighting systems and other electrical devices in modern buildings. Application Examples Control of dimmable LED lights and incandescent lamps. Automation of roller shutters and gates. Integration into smart home systems for individual adjustment of lighting moods. The module features 8 button inputs that allow for individual programming. The integrated operating programs enable switching and dimming of the outputs as well as separate adjustment of brightness and change speed. Additionally, up to 100 lighting scenes can be stored per output. Technical Data Integrated power supply: 230V ±15%, 0.5W, pulse-proof up to 4kV Dimensions: 50mm Ø x 22mm Connection via approx. 20cm long single wires 0.75mm² Protection class: IP20 Communication with up to 30000 modules, max. 250 modules per bus level

Sensor module for flush-mounted box The LCN-UPS module is a versatile sensor module designed for use in flush-mounted boxes with an operating voltage of 230V. It allows control of up to 64 target addresses and offers 192 functions that can be programmed individually. Application examples Control of lighting and other electrical devices in residential and commercial spaces. Integration into existing smart home systems for process automation. Use in conjunction with DSI-Dali interfaces for extended functionality. The module offers 8 button inputs and an integrated pulse measurement input for remote control receivers. It allows evaluation over 5 thresholds with hysteresis and includes two continuous controllers that can be used independently of threshold processing. Technical data Integrated power supply: 230V ±15%, 0.4W, pulse-proof up to 4kV Dimensions: 50mm Ø x 12mm Connection via approx. 20cm long single wires 0.75mm² Communication with up to 30000 modules, max. 250 modules per bus level

Universal Roller Shutter/Jalousie Module for Flush-Mounting Box The LCN-UMR module is a state-of-the-art sensor-actuator module specifically designed for controlling roller shutter and jalousie motors. It features two switchable, interlocked relay outputs with a nominal voltage of 230V. The module is ideal for integration into flush-mounting boxes and allows for easy installation and commissioning. Connection Supply voltage: 230V AC ±15%, 50/60Hz (110V AC available) Power consumption: <0.5W Network connection: 5 wires with ferrule 0.75mm² Sensor side connection: T- and I-connection Outputs Type: 2x relays each 6A, interlocked Mechanical lifespan: 1,000,000 switching cycles Switching power: recommended max. 800W Inrush current: max. 50A 8/10µs Installation Operating temperature: -10°C to +40°C Humidity: max. 80% rel., non-condensing Environmental conditions: Use in fixed installation according to VDE632, VDE637 Protection class: IP20 when installed in flush-mounting box, only fixed installation Dimensions (WxDxH): 50mm Ø x 22mm

Sensor module for flush-mounted box 24V~ The LCN-UPS24 flush-mounted module is a highly flexible sensor module specifically designed for integration into dry rooms. It is installed directly in flush-mounted/electronic boxes behind switches, sockets, or in distribution boxes. The module offers a sensor input (T-connection) for connecting conventional switches, LCN-GTx switches, or other peripheral devices. In addition, an I-connection is available that supports a variety of functions, including IR receivers, GT switches, and EnOcean transmitters/receivers. Application Areas Cost-effective connection of LCN sensors and KNX touch sensors or EnOcean wireless touch sensors. Individual room control for cooling, heating, and ventilation. Access control with IR remote control and transponders. Utilization of existing low-voltage wiring. Automation controls with timers and links. Tableau systems with status LEDs and hierarchical links of permissions. Alarm systems with multiple zones and complex conditions. Links across trade boundaries for high functionality. Note: All functions can be used independently and are available simultaneously. Hardware Features Supply voltage: 20-30 Volts~, 50/60 Hz T-connection for up to eight buttons via button converters. I-connection for the operation of LCN-RR, IR remote control receivers, temperature sensors, and other devices. Function Description Four simulated outputs with timers for various functions. Support for DALI groups via LCN-DDR. Connection for eight conventional buttons with extensive command processing. LCN tableau functions with four states. Decoding of the IR remote control receiver with extended functions. Additional functions include the acquisition of measured values, analog value processing, transponder data processing, and code lock functions. The module also provides a bridging of power outages for up to 20 seconds.
